DarwinFPV adalah tim desain dari China dengan pengalaman desain yang kaya di bidang drone balap FPV. Kami bertujuan untuk menyediakan produk berbiaya rendah dan berkinerja tinggi untuk setiap teman di dunia yang suka terbang. Terima kasih telah memilih produk kami dan semoga penerbangan Anda bahagia dan aman
Item name： Baby Ape / BabyApe
Comes without battery, charger, receiver or remote control.
142mm Racing Frame Kit | Wheel base: 142mm Frame arm thickness: 2.5mm Other thickness:1.5mm Frame kit material: 3K carbon fiber |
11044300KV 2-3S Brushless Motor | KV: 4300KV Lipo cell: 2-3S Weight: 6.0g |
AIO 4 IN 1 15A BLHeli_S ESC | Input voltage: 1-3SLiPo Continuous current: 15A Pe ak current:17A (10S) BEC output: no Main control chip:EFM8BB21 Firmware upgrade: Supports Dshot600/Oneshot125 MOS: 3*3 |
F411 AIOFlight Controller | Main control chip: STM32F411 Sensor: MPU6000 or ICM20689 Integrated OSD PPM/DSM/IBUS/UAR share: UART1-RX Mounting holes distance: 25.5*25.5mm Supports Betaflight firmware |
Baby APE Darwin700TVL Camer | Resolution:700TVL Lens: 1.8mm Input: 3.5-5V TV System: PAL/NTSC |
5.8G 40CH 0mW/25mw/200mw switchable VTX | Supports TBS SmartAudio Transmitting power: 0mW/25mW/100mW/200mW switchable Channel: 40CH Full video format: NTSC/PAL Input voltage: 7V~24V Power dissipation: +12V/600MW Size: 25×20×6mm Weight: ≤3.2g (except antenna) With copper pipe mini antenna (ipex antenna) |
30163-blade propeller | Material: PC Mounting hole: 1.5mm Center thickness: 5.5mm Quantity: 2 pairs Weight: 1.18g a pair |
Lipo Battery | Not included |
